Blue Seal Evolution
Blue Seal Evolution G504D, 4 Burner Oven Range
600 × 812 × 1085mm
$7,224
ex GST$9,418
or $171.21 +GST / week
The Blue Seal Evolution E516S-RB is a versatile 6 Hot Plate Sealed Hob Cooktop designed with a refrigerated base for added functionality. This electric cooktop features 6 cooking zones with 2.6kW cast iron hot plate elements, each equipped with thermal protection for reliable performance. The self-contained suite includes a matched modular refrigerated base with a ventilated system using R134a refrigerant, capable of maintaining a temperature range of -2 to +8 degrees Celsius (Tropical Climate rated). The refrigerated base features two GN 1/1 drawers with a 100mm deep pan capacity and is equipped with a digital control electronic thermostat with automatic defrost. The cooktop section includes a vitreous enamelled control panel, large heat-resistant reinforced control knob, and power indicator lights for each element. The overall construction involves aluminised steel internals and a heavy-duty stainless steel finish, ensuring durability and ease of cleaning. This unit is designed for easy installation and service in commercial kitchen environments.
Blue Seal Evolution E516S-RB is a professional 6-burner electric cooktop built for high-output kitchens that need both cooking power and integrated refrigeration. The sealed hob design keeps the cooking surface clean and easy to maintain, while digital electronic controls give you precise heat management across all stations. With 15.6 kW of burner output, this unit handles serious volume without compromise.
What sets this cooktop apart is the refrigerated base—two generously sized GN 1/1 drawers sit underneath, holding ingredients at 0–4°C and eliminating the need for a separate under-bench fridge in tight spaces. The 304 stainless steel construction and ventilated tropical-rated cooling system ensure durability in demanding commercial environments. Flame failure protection on the open burners adds a safety layer that busy kitchen teams will appreciate.
Ideal for hotels, clubs, catering outlets and large restaurants where prep space and cooking power must work hand in hand, the E516S-RB combines practicality with robust build quality. It's freestanding, meaning quick installation and flexibility in your kitchen layout.
| External (W × D × H) | 900 × 812 × 1085 mm |
|---|---|
| Capacity | 2 x GN 1/1 Drawers |
| Cooking Surface Area | 900 x 480 |
| Product Weight (kg) | 75 |
| Assembly Type | Pre-Assembled |
|---|---|
| Base Type | Refrigerated Base |
| Colour | Stainless Steel |
| Door Type | Drawer |
| Installation Type | Freestanding |
| Material | 304 Stainless Steel |
| No. of Doors | 2 |
| Splash Back | Yes (165mm) |
| Undershelf | Refrigerated Base |
| Electricity Consumption | See Power Rating |
|---|---|
| Power Rating | 15.6 kW / 22A / 3P+N+E / 400-415Vac / 50/60Hz |
| Power Supply | 230-240 Vac / 1P+N+E / 50/60 Hz |
| Voltage/Phase | 400-415V 3P+N+E |
| BTU Rating | 53227 BTU/h |
|---|---|
| Burner Output | 15.6 kW |
| Burner/Element Output | 15.6 kW |
| Fuel Type | Electric |
| Number of Burners | 6 |
| Cooling Type | Ventilated / Tropical Rated |
|---|---|
| Refrigeration Type | Ventilated / R134a |
| Temperature Range | 0°C to 4°C |
| Control Type | Sealed Hob Control |
|---|---|
| Display Type | Digital Electronic |
| Temperature Control | Digital / -2°C to +8°C |
| Warranty | 12 months — Parts and Labour |
|---|---|
| Country of origin | New Zealand |
| Series | Evolution Series |
| Destination | Lead time |
|---|---|
| Melbourne metro — DHT truck | 1–3 business days if in stock |
| Regional Victoria | 2–4 business days |
| Sydney / Adelaide metro | 3–6 business days |
| Brisbane metro | 4–7 business days |
| Perth / NT / TAS | 7–14 business days |
Estimated delivery for items in stock. Melbourne metro delivery on our own truck is estimated at 1–3 business days. Items that are not in stock, or are made to order, take longer — we confirm the lead time when we quote.
Our delivery network also services Sydney, Canberra, Brisbane and Adelaide, and other areas on request. Delivery is quoted per order, and we confirm the delivery date when we quote freight. The times below are estimates only, not a guaranteed delivery date.
